A Diversity of Dunes in Renaudot Crater
NASA/JPL-Caltech/UArizona
A Diversity of Dunes in Renaudot Crater
ESP_085411_2225  Science Theme: Seasonal Processes
Renaudot is a 64-kilometer diameter impact crater located on the border of Utopia and Terra Sabaea, Mars. It contains a variety of dunes that vary in size, shape, and composition.

Both dark and light-toned dunes are located on the floor of this crater. The dark-toned dunes are likely basaltic sand while the light-toned dunes source from other materials. The floor underlying the dunes is an eroded lighter-toned surface consisting of rougher, angular blocky material or cracked, cemented surface materials.

It is likely that the sources for these dunes are outside of the crater and sediment was blown in by prevailing winds. Windward-facing dune slopes tend to have lower slopes while those pointing in the downwind direction are steeper. This suggests that the windward direction for the basaltic and larger light-toned dunes is generally towards the south, although there are smaller sets of differently aligned dunes suggesting varying wind directions.

Written by: Ginny Gulick  (8 July 2025)

Acquisition date
15 October 2024

Local Mars time
14:16

Latitude (centered)
41.977°

Longitude (East)
62.505°

Spacecraft altitude
296.9 km (184.5 miles)

Original image scale range
60.3 cm/pixel (with 2 x 2 binning) so objects ~181 cm across are resolved

Map projected scale
50 cm/pixel and North is up

Map projection
Equirectangular

Emission angle
8.3°

Phase angle
51.5°

Solar incidence angle
57°, with the Sun about 33° above the horizon

Solar longitude
345.8°, Northern Winter

For non-map projected images
North azimuth:  96°
Sub-solar azimuth:  317.1°
JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (216MB)

IRB color
map-projected   (72MB)

JP2 EXTRAS
Black and white
map-projected  (114MB)
non-map           (141MB)

IRB color
map projected  (35MB)
non-map           (61MB)

Merged IRB
map projected  (216MB)

Merged RGB
map-projected  (206MB)

RGB color
non map           (117MB)
BONUS
4K (TIFF)
8K (TIFF)
10K (TIFF)

ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images
