HiRISE | Strange Mesas in Noachis Terra (ESP_086811

NASA/JPL-Caltech/UArizona

Strange Mesas in Noachis Terra
ESP_086811_1615 Science Theme:

This image shows several mesa-like features in the Noachis Terra region of Mars. A mesa is a steep-sided, flat-topped mountain or hill. While the larger features in this image are elevated areas of land surrounded by cliffs, the smaller “mesas” seem to be saucer-shaped in that the interiors of the mesas are at a lower elevation than the surrounding cliffs.

The saucer-like shape of these features is unusual and begs the question of how they formed, and it’s not apparent from this single image. The HiRISE team plans to acquire a second picture to provide stereo coverage, from which we can create a 3D digital elevation model. This elevation model may help us figure out how these strange mesas formed.

Written by: Chris Okubo (26 May 2025)

Acquisition date
01 February 2025

Local Mars time
14:59

Latitude (centered)
-18.107°

Longitude (East)
6.901°

Spacecraft altitude
260.9 km (162.1 miles)

Original image scale range
from 26.1 cm/pixel (with 1 x 1 binning) to 52.2 cm/pixel (with 2 x 2 binning)

Map projected scale
25 cm/pixel and North is up

Map projection
Equirectangular

Emission angle
1.8°

Phase angle
56.9°

Solar incidence angle
56°, with the Sun about 34° above the horizon

Solar longitude
38.4°, Northern Spring

For non-map projected images
North azimuth: 97°
Sub-solar azimuth: 40.2°

JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (573MB)

IRB color
map-projected   (464MB)

JP2 EXTRAS
Black and white
map-projected (270MB)
non-map           (433MB)

IRB color
map projected (152MB)
non-map           (387MB)

Merged IRB
map projected (178MB)

Merged RGB
map-projected (166MB)

RGB color
non map           (384MB)

ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images
