Probing Below the Surface with Impact Craters
ESP_089323_2180  Science Theme: Impact Processes
When they form, impact craters dig up material from below the surface and throw it outwards into what geologists call an ejecta blanket. The fastest ejected material travels the furthest so material from different depths can end up at different distances from the crater.

This HiRISE image shows a pedestal crater in Arcadia Planitia that has material of different brightness and color at various distances from the crater. This could tell us more about the material that’s buried below the surface here, but the situation is complex.

These pedestal craters have been significantly eroded so that not all parts of the eject blanket are equally preserved. A detailed geologic map of features like this can often tease these confounding factors apart and tell us more about what’s under the surface of Mars.

Written by: Shane Byrne  (17 March 2026)

This is a stereo pair with ESP_089600_2180.

Acquisition date
16 August 2025

Local Mars time
15:24

Latitude (centered)
37.684°

Longitude (East)
175.896°

Spacecraft altitude
300.3 km (186.6 miles)

Original image scale range
60.3 cm/pixel (with 2 x 2 binning) so objects ~181 cm across are resolved

Map projected scale
50 cm/pixel and North is up

Map projection
Equirectangular

Emission angle
5.7°

Phase angle
53.1°

Solar incidence angle
47°, with the Sun about 43° above the horizon

Solar longitude
125.7°, Northern Summer

For non-map projected images
North azimuth:  97°
Sub-solar azimuth:  359.5°
JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (148MB)

IRB color
map-projected   (51MB)

JP2 EXTRAS
Black and white
map-projected  (66MB)
non-map           (85MB)

IRB color
map projected  (16MB)
non-map           (39MB)

Merged IRB
map projected  (148MB)

Merged RGB
map-projected  (142MB)

RGB color
non map           (75MB)
ANAGLYPHS
Map-projected, reduced-resolution
Full resolution JP2 download
Anaglyph details page

ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images
